Toyota Crown S220 airbag control unit repair

What is a Toyota Crown S220 airbag control unit?

The Toyota Crown S220 airbag control unit is the central safety unit in the vehicle, responsible for monitoring, activating, and controlling all occupant restraint systems. It collects sensor data, decides whether to deploy airbags and seatbelt pretensioners in the event of a collision, and stores important crash information.

This electronic control unit, also known as the SRS Airbag ECU, is crucial to the passive safety of the Toyota Crown S220.

It ensures that the airbags are deployed precisely and within milliseconds in the event of an impact.

In addition, it continuously monitors the functionality of the entire airbag system and indicates possible malfunctions via the warning light on the dashboard to ensure the safety of the vehicle occupants at all times.

Why is the Toyota Crown S220 airbag control unit defective?

A Toyota Crown S220 airbag control unit is often defective because it permanently stores crash data after an accident that needs to be erased, or because internal electronic components fail. Communication or power supply errors can also render the module inoperable, necessitating a professional Toyota Crown S220 airbag control unit repair.

After an airbag is deployed, the control unit stores indelible crash data that blocks further operation of the system.

Other causes of failure can be water damage, short circuits or age-related material fatigue, which lead to a malfunction of the essential safety system.

A defective control unit prevents the airbags and seat belt pretensioners from functioning properly, which significantly impairs vehicle safety and requires immediate action.

Common error codes for Toyota Crown S220 airbag control unit repair

When repairing a Toyota Crown S220 airbag control unit, specific error codes are crucial for identifying the cause of a malfunction. These codes directly indicate problems within the control unit or its closely connected circuits, enabling targeted diagnostics in the workshop.

• B1000: Control unit communication error → Indicates problems with communication between the diagnostic tool and the control unit or internal ECU communication problems → Common cause: internal control unit malfunction or connection problems.
• B1811: Driver Airbag Deployment Circuit 2 Malfunction → Indicates an open or malfunction in the driver airbag second stage circuit → Often caused by a faulty clock spring, steering wheel connector, wiring, or the control module itself.

These specific error codes are primarily associated with the airbag control unit and facilitate targeted troubleshooting.

To accurately diagnose and clear these error codes, a manufacturer-specific diagnostic tool such as Toyota TechStream is required at a specialist workshop.

What part numbers are available for the Toyota Crown S220 airbag control unit repair?

For a successful Toyota Crown S220 airbag control unit repair, exact part numbers are essential to ensure part compatibility. Only with the correct OEM or verified manufacturer part numbers can we guarantee that the airbag control unit fits perfectly with the vehicle model and reliably fulfills its safety functions.

Two precisely verified OEM part numbers are relevant for the airbag control unit of the Toyota Crown S220, which enable reliable identification.

The official Toyota OEM part number is **89170-42D50**, which is listed directly for the Crown model S220 (model year 2018-2022) and refers to the Airbag Control Module.

Alternatively, there is the manufacturer part number **152100-4560** from Autoliv, a well-known OEM supplier for airbag systems, which is also listed for the control unit of the S220 Crown and is directly related to the Toyota OEM number.

It is crucial to use only these verified numbers when purchasing airbag control unit repairs to avoid malfunctions and safety risks.
